Product Introduction
Mobile energy storage charger is a product that serves the new energy vehicle industry. Widely used in application scenarios such as road rescue for new energy vehicles, emergency power replenishment, and on-site charging services. It is an extension and supplement to the operation services of new energy vehicle charging stations, providing more convenient and efficient charging services for new energy vehicle owners.
Product Specifications
● Supports V2G/V2L/V2H
● RFID Reader
● OCPP 1.6J Compliant
● Battery capacity: 33 kWh
● Vehicle mounted mobility
Product Data Parameters
| Category | Specifications | Data parameters |
| Appearance and Structure | Dimensions (L x D x H) | 1760mm x 1080mm x 1023mm |
| Weight | 300kg | |
| Charging cable length | 5m | |
| Connectors | CCS || CCS2 || CHAdeMO || GBT | |
| Electrical Indicators | Capacity | 33kwh |
| Input voltage | 400VAC / 480VAC (3P+N+PE) | |
| Enter frequency | 50/60Hz | |
| Output voltage | 200 – 1000 VDC | |
| Output current | 0-100A | |
| Rated Power | 30kW | |
| Efficiency | ≥94% at nominal output power | |
| Power factor | >0.98 | |
| Communication Protocol | OCPP 1.6J | |
| Functional Design | Display | 7’’ LCD with touch screen (Optional) |
| RRD system | ISO/IEC 14443A/B | |
| Access Control | RFID: ISO/IEC 14443A/B || Credit Card Reader (Optional) | |
| Communication | Ethernet‑Standard || 3G/4G Module (Optional) | |
| Power Electronics Cooling | Air cooling | |
| Work Environment | Operating temperature | -30°C to 55°C |
| Working||Storage Humidity | ≤ 95% RH || ≤ 95% RH (Non‑condensing) | |
| Altitude | <2000m | |
| Ingress Protection | IP54 || IK10 | |
| Safety Design | Safety standard | GB/T, CCS2, CCS1, CHAdeMo, NACS |
| Security Protection | Overvoltage protection, lightning protection, overcurrent protection, leakage protection, waterproof protection, etc. | |
| Emergency stop | Emergency stop button disables output power |
